ArrowJet Eco 330R

ArrowJet Eco 330R –Your smart entry into industrial digital label printing
Robust build. Lower costs. Faster growth.
When your label work is getting bigger than desktop printers but you don’t want the complexity or overhead of a large press ArrowJet Eco 330R is the ideal step up. It’s a compact industrial, single-pass digital press built to help converters and in-house teams produce profitable labels and flexible packaging with speed, clarity, and consistency.
Industrial output without industrial headaches
Eco 330R delivers true production performance in a footprint that fits real shops. It runs on single-phase power, doesn’t require an air compressor, and installs easily—so you can start producing faster and keep operating costs under control.
What you get:
- Up to 20 m/min printing speed for quick turnarounds and more jobs per shift
- Up to 324 mm print width to handle a wide range of label formats
- Ultra-sharp detail at 1600 × 1600 dpi for text, gradients, barcodes, and fine graphics
- Cost-efficient CMYK water-based pigment inks designed for economical production
Specifications
Brochure
Specifications
| Specification | Details |
|---|---|
| Print Technology | Single-pass digital inkjet |
| Print Engine | Memjet DuraFlex® |
| Ink Set | CMYK water-based pigment |
| Max Print Width | 324 mm |
| Speed | Up to 20 meters/min |
| Resolution | 1600 × 1600 dpi |
| Max Media Diameter | 350 mm |
| Max Roll Weight | 40 kg |
| Max Roll Size | 385 mm |
| Drying | IR Dryer (optional) |
| RIP | Xitron / Arrow RIP |
| Power | Single-phase 230V |
| Machine Size | 78 (L) × 106 (W) × 168 (H) cm |
| Machine Weight | 430 kg |
