Arrow Lam 380
380 mm Reel-to-Reel Thermal Laminating Machine for Printed PET Films, Labels, Catalogues & Print Finishing
The Arrow Lam 380 is a compact reel-to-reel thermal laminating machine designed for consistent lamination of printed roll-fed and sheet-based print applications. Built with a heavy-duty structure, hydraulic nip pressure system, precision-controlled heated roller, and AC frequency-controlled drive, the machine delivers reliable bonding and smooth finish quality for demanding print and packaging workflows.
With a maximum lamination width of 380 mm / 15 inches, the Arrow Lam 380 is especially suitable for printed PET films, labels, catalogues, photo albums, book wrappers, and other commercial print finishing applications requiring gloss, matte, silky matte, or velvet thermal lamination.
The machine is designed as a practical, durable, and efficient thermal lamination solution for printers, label manufacturers, packaging converters, and print finishing units looking for strong film adhesion, stable operation, and long-term production reliability.
Overview
Features
Specifications
Applications
Overview
In print and packaging, lamination plays an important role in improving surface appearance, durability, handling resistance, and product presentation. The Arrow Lam 380 applies a thermal film layer over printed substrates to enhance finish quality while protecting the printed surface.
Its reel-to-reel configuration supports continuous production, making it suitable for roll-fed print and packaging applications. The machine combines hydraulic pressure, controlled heating, and manual operator adjustments to achieve reliable lamination results across different job types.
Features
Continuous Reel-to-Reel Lamination
The Arrow Lam 380 supports reel-to-reel thermal lamination, making it suitable for continuous roll-fed production and reducing manual handling during longer print finishing runs.
Hydraulic Nip Pressure
The hydraulic nip pressure system helps ensure strong bonding between the thermal film and substrate. It supports uniform pressure application for improved lamination quality and consistent results.
Precision Heated Roller Control
The heated roller is designed for controlled thermal film activation. Heat is precisely managed using an imported slip ring system, helping maintain stable lamination quality during production.
Imported AC Frequency-Controlled Drive
The machine uses an imported AC frequency-controlled variable speed drive from Control Techniques, UK, allowing operators to adjust machine speed according to the material, film type, and job requirement.
Manual Operator Control
The Arrow Lam 380 is a basic, operator-controlled model. Web tension, film tension, and nip pressure are manually adjusted, giving operators direct control over the lamination process.
Compact, Rigid & Sturdy Construction
With a compact footprint and approximate machine weight of 750 kg, the Arrow Lam 380 is built for industrial durability, stable operation, and long-term use in production environments.
Efficient Power Consumption
The machine is engineered for efficient operation with a total power consumption of approximately 4.5 kW, making it a practical choice for print and packaging units seeking reliable thermal lamination with controlled energy usage.
Specifications
Specification | Details |
Product / Model Name | Arrow Lam 380 |
Machine Type | Reel-to-Reel Thermal Laminating Machine |
Maximum Lamination Width | 380 mm / 15 inches |
Roller Configuration | 2 + 3 Rollers |
Heated Roller Diameter | 268 mm |
Counter Pressure Roller Diameter | 130 mm |
Supported Media Thickness | 90 GSM – 350 GSM |
Laminating Speed | 12 – 15 m/min |
Temperature Range | 90°C – 110°C |
Pressure System | Hydraulic Nip Pressure |
Drive System | Imported AC Frequency-Controlled Variable Speed Drive |
Drive Brand | Control Techniques, UK |
Film Types | BOPP, PET thermal films; gloss, matte, silky matte, velvet |
Typical Film Thickness | 24 microns, 27 microns, 32 microns |
Film Core Bore | 75 mm |
Maximum Film Roll Diameter | 350 mm |
Voltage | 440V |
Phase | Three Phase |
Heater Power | 3 kW |
Total Power Consumption | 4.5 kW |
Machine Dimensions | 93″ L × 53″ W × 61″ H |
Machine Weight | Approx. 750 kg |
Controls | Manual web tension, film tension, and nip pressure |
Applications
Key Applications
The Arrow Lam 380 is suitable for thermal lamination of:
- Printed PET films
- Labels and label stock
- Catalogues
- Photo albums
- Book wrappers
- Commercial printed materials
- Flexible packaging materials
- Printed rolls
- Promotional print products
- Specialty print finishing jobs
Supported Laminating Films
The machine supports commonly used thermal lamination films, including:
- BOPP thermal films
- PET thermal films
- Gloss films
- Matte films
- Silky matte films
- Velvet films
Typical thermal film thickness options include 24 microns, 27 microns, and 32 microns.
The machine supports film rolls with a 75 mm core bore and a maximum film roll diameter of 350 mm. Film width should be selected according to the job width and is generally maintained around 3–5 mm less than the job width for proper processing.
Why Choose Arrow Lam 380?
The Arrow Lam 380 is designed for businesses that need a compact yet sturdy thermal laminating machine for consistent production results.
Key advantages include:
- Designed and engineered for optimum lamination results
- Precise heat control through imported slip ring system
- Hydraulic nip pressure for strong film-to-substrate bonding
- Suitable for printed PET films, labels, catalogues, photo albums, and book wrappers
- Compact design with rigid and sturdy construction
- Efficient operation with relatively low power consumption
- Practical manual controls for operators who prefer direct process adjustment
Upgrade Your Lamination Process
Enhance your print finishing and packaging production with the Arrow Lam 380 reel-to-reel thermal laminating machine. Designed for reliable bonding, smooth finish quality, and efficient operation, it is a practical solution for printed PET films, labels, catalogues, wrappers, and commercial print finishing applications.
Contact Arrow Systems today to learn more about the Arrow Lam 380 and find the right lamination solution for your production requirements.
